60KW-120KW Type 3 EVCS Plug In DC E Vehicle EV Fast Charging Station

60KW-120KW Type 3 EVCS Plug In DC E Vehicle EV Fast Charging Station
60KW-120KW Type 3 EVCS Plug In DC E Vehicle EV Fast Charging Station 60KW-120KW Type 3 EVCS Plug In DC E Vehicle EV Fast Charging Station 60KW-120KW Type 3 EVCS Plug In DC E Vehicle EV Fast Charging Station 60KW-120KW Type 3 EVCS Plug In DC E Vehicle EV Fast Charging Station 60KW-120KW Type 3 EVCS Plug In DC E Vehicle EV Fast Charging Station 60KW-120KW Type 3 EVCS Plug In DC E Vehicle EV Fast Charging Station

Large Image :  60KW-120KW Type 3 EVCS Plug In DC E Vehicle EV Fast Charging Station

Product Details:
Place of Origin: Guangdong, China
Brand Name: KIWI
Model Number: F6-DC1000V-120KW/AB
Payment & Shipping Terms:
Price: $20,000.00/pieces 1-1 pieces
Packaging Details: professional plywood box
Supply Ability: 500 Piece/Pieces per Month
Contact Now

60KW-120KW Type 3 EVCS Plug In DC E Vehicle EV Fast Charging Station

Description
Installation Method: Floor-standing Start-up And Billing Method: RFID,plug And Charge,Scan QRCode
Input Voltage: Three Phase AC 380V±20%(ABC+N+PE) Input Current Range: AC 0A~182A
Grid Frequency: 50Hz±10Hz Output Current: 60KW-120KW DC 0 ~400A
Output Voltage: DC 150V~1000V IP Protection Level: IP54
OCPP: OCPP 1.6J/1.5J AC Leakage: RCD B
Port: Shenzhen,Foshan,HK,etc.
Highlight:

120KW Type 3 EV Charging Station

,

EVCS Plug EV Fast Charging Station

,

120KW EV Fast Charging Station

60KW-120KW Best Type 3 EVCS Plug In DC E Vehicle EV Fast Charging Station for Charging



60KW-120KW Type 3 EVCS Plug In DC E Vehicle EV Fast Charging Station 0
60KW-120KW Type 3 EVCS Plug In DC E Vehicle EV Fast Charging Station 1
Item
Discription
Rated Power
120KW
Charging mode
RFID,plug and charge,OCPP(APP/QR Code)
Size (H * W * D)
700*340*1670mm
Weight
250kg
Plug wire length
3.5m(customizable)
Plug standard
CHAdeMO or CCS1 orCCS2 orGB/T
Protection level
IP54
Cooling Method
Wind cooling
Standard :LAN
Optional :WIFI,4G
server communication, APP communication
OCPP
OCPP 1.6J/1.5J
Input

Input Voltage
Three-phase AC380V 50/60Hz(L1+L2+L3+N+PE)
Input Current
Each phase 0~182A
Leakage Protection
Type B RCD 30mA + 6mA
Operating temperature
-20℃~60℃
Output

Output voltage
DC 150V~1000V
Output current
120KW DC 0 ~100A
Human-computer interaction

LED indicator
Power supply, charging green, fault red
LCD
7 Inch HD high-brightness industrial resistance display
60KW-120KW Type 3 EVCS Plug In DC E Vehicle EV Fast Charging Station 2
60KW-120KW Type 3 EVCS Plug In DC E Vehicle EV Fast Charging Station 3
60KW-120KW Type 3 EVCS Plug In DC E Vehicle EV Fast Charging Station 4
60KW-120KW Type 3 EVCS Plug In DC E Vehicle EV Fast Charging Station 5
60KW-120KW Type 3 EVCS Plug In DC E Vehicle EV Fast Charging Station 6
60KW-120KW Type 3 EVCS Plug In DC E Vehicle EV Fast Charging Station 7
60KW-120KW Type 3 EVCS Plug In DC E Vehicle EV Fast Charging Station 8
60KW-120KW Type 3 EVCS Plug In DC E Vehicle EV Fast Charging Station 9
60KW-120KW Type 3 EVCS Plug In DC E Vehicle EV Fast Charging Station 10
60KW-120KW Type 3 EVCS Plug In DC E Vehicle EV Fast Charging Station 11
60KW-120KW Type 3 EVCS Plug In DC E Vehicle EV Fast Charging Station 12
60KW-120KW Type 3 EVCS Plug In DC E Vehicle EV Fast Charging Station 13
60KW-120KW Type 3 EVCS Plug In DC E Vehicle EV Fast Charging Station 14
60KW-120KW Type 3 EVCS Plug In DC E Vehicle EV Fast Charging Station 15
60KW-120KW Type 3 EVCS Plug In DC E Vehicle EV Fast Charging Station 16
60KW-120KW Type 3 EVCS Plug In DC E Vehicle EV Fast Charging Station 17
60KW-120KW Type 3 EVCS Plug In DC E Vehicle EV Fast Charging Station 18
Customers Also LIke to Ask These Questions
Q: How is your electric vehicle charging station after-sale service?
A:1/We will build a whatsapp/skype/wechat service group with technical engineers and company leader if need;
2/We provide 24/7 online service,so you're welcome to contact us any time you need;
3/Will change the part for free during warranty if non-human damage,for other problems,we'd like to supply customer the part at original cost.

Q: How is your payment method?
A: Same as other ev charging stations suppliers,normally 30%-50% deposit and balance paid off before shipment,special requirement customer please contact us for further discussion.

Q: How long is your normal delivery time?
A: 1/For stock ev charger,can arrange the shipment immediately after you confirm the order;
2/For custom AC ev charger less than 100pcs,normally 7-15 days;
3/For custom DC ev charger less than 100pcs,normally 15-25 days;

Q: Can I use my own card or app at your electric car charging stations?
A: Normally the RFID card and app have to identify our electric charger,so we will provide you 3 free RFID card for each charger.

Q:Will your electric car charger charging slower in winter?
A:The electric charging station may need a little longer warm up time before normal run,but this is very small change,it won't
influence the output power,so we can ignore this influence.

Q:Can you provide a video how to install the electric vehicle charger?
A:Yes we have the installation guide video,it's very easy and anyone who know a little about electricity safety can finish this
work,we will also be ready online to help your any possible question.

Q:How can I become your exclusive agency?
A:Only if you have this interest,you can be our agent if we don't have exclusive agent in your market.
if you want to be exclusive agent,we will have an annual sales amount target requirement,welcome to further discuss about more details,we're open to any constructive advice.
