Product Details:
|
| Type: | 7KW Portable Charger | Model: | X7 (G07), X7 SUV (G07), MODEL Y (5YJY) |
|---|---|---|---|
| Year: | 2019-, 2019- | Function: | DC EV Charger |
| Car Fitment: | Tesla, Bmw | Charging Port: | NO |
| Connection: | CCS1/CCS2/GB/T | Voltage: | 220V |
| Warranty: | 1 Year | Design Style: | Simple |
| Installation Method: | Portable | Charging Mode: | Automatic Charging After Starting The Button |
| Input Voltage: | Single-phase AC 220V/50Hz(L+N+PE) AC100V~AC220V | Input Current Range: | AC 0A~32A |
| IP Protection Level: | IP54 | Output: | DC 150V~750V,20A |
| RS485: | Point To Point Communication | Power Unit: | 7KW Power Output |
| Cooling Fan: | Ensure Long-time Work And Heat Dissipation | Leakage Switch: | 30mA AC Current Protection Switch |
| Port: | Shenzhen,Foshan,etc. |
Item | Value |
Installation Method | Portable |
Rated Power | 7KW DC |
Charging mode | Automatic charging after starting the button |
Size (H * W * D) | 482*293*152mm |
Weight | 15kg |
Input voltage | single-phase AC 220V/50Hz AC100V~AC220V |
Input Current | Each phase 0~32A |
Leakage Protection | 30mA AC current protection switch |
Output voltage | DC 150V~750V |
Output current | DC 20A |
Plug wire length | 5m(customizable) |
Plug standard | CCS1/CCS2/GB/T |
LCD | 4.3 inch color touch LCD |
Protection level | IP41 |
Noise | ≤55dB |
Operating temperature | -20°C～+50°C |
Safety protection | Over voltage protection, over current protection, output short circuit protection, reverse connection protection, adhesion detection, over temperature protection, leakage protection, insulation detection |
