Product Details:
|
| Interface Standard: | CCS | Output Current: | DC |
|---|---|---|---|
| Output Power: | 40kW | Input Voltage: | 380V |
| Installation Method: | Wall Mounted/column | Charging Mode: | Automatic Charging After Starting The Button |
| Input Voltage: | AC380V±20% | Input Current Range: | AC 0A~65A |
| IP Protection Level: | IP54 | Output: | DC 200V~1000V,1A--130A |
| RS485: | Point To Point Communication | Rated Power: | 40KW |
| Cooling Way: | Intelligent Air Cooling | The Grid Frequency: | 55 Hz±10 Hz |
| Port: | Shenzhen,Foshan,etc. |
Item | Value |
Installation Method | wall-mounted/Column(optional) |
Rated Power | 30KW/40KW |
Start-Up And Billing Method | RFID、plug and charge、CMS（Scan QR Code） |
Input Voltage | Three phase DC1000V±20%（ABC+N+PE） |
Grid Frequency | 50Hz±10Hz |
Input Current Range | AC 0A~45A |
Power-On Input Impulse Current | ≤ Maximum input current 120% |
Input Protection | Overvoltage, dustproof and waterproof, overload, short circuit protection, lightning protection, energy load output |
Input Break | With AC 30mA leakage plastic case |
Output Current | 30KW/40KW, DC 0~60A |
The Output Voltage | DC 200V~1000V |
Effectiveness | ≥95% |
Working Temperature | -30℃～+55℃; -40℃(±4℃) module start-up; derating use above 55℃; shutdown above 70℃ |
IP Protection Level | IP54 |
Cooling Method | Smart air cooling |
Noise | ≤60dB |
