Product Details:
|
| Interface Standard: | CCS2/CHADEMO/CCS1/GBT | Output Current: | 400A |
|---|---|---|---|
| Output Power: | 60KW/80KW | Input Voltage: | AC380V |
| Installation Method: | Floor-standing | Start-up And Billing Method: | RFID,plug&charge,Scan QR Code |
| Input Voltage: | Three Phase AC 380V±20%(ABC+N+PE) | Input Current Range: | AC 0A~136.5A |
| Grid Frequency: | 50Hz±10Hz | Output Current: | DC 0 ~300A |
| Output Voltage: | DC 150V~1000V | IP Protection Level: | IP54 |
| OCPP: | OCPP 1.6J/1.5J | AC Leakage: | RCD |
| Port: | Shenzhen,Foshan,HK,etc. |
Features | Discription | ||||||
Rated Power | 60KW/80KW | ||||||
Charging mode | RFID、plug and charge、Scan QRCode | ||||||
Size (H * W * D) | 700*340*1670mm | ||||||
Weight | 250kg | ||||||
Plug wire length | 3.5m(customizable) | ||||||
Plug standard | CHAdeMO or CCS1 orCCS2 orGB/T | ||||||
Protection level | IP54 | ||||||
Cooling Method | Wind cooling | ||||||
Standard :LAN Optional :WIFI、4G | server communication, APP communication | ||||||
CPP | OCPP 1.6J/1.5J | ||||||
Input | ||||||||
Input Voltage | Three-phase AC380V 50/60Hz（L1+L2+L3+N+PE） | |||||||
Input Current | Each phase 0~136.5A | |||||||
Leakage Protection | Type B RCD 30mA + 6mA | |||||||
Operating temperature | -20℃~60℃ | |||||||
Output | ||||||||
Output voltage | DC 150V~1000V | |||||||
Output current | 0 ~300A | |||||||
Human-computer interaction | ||||||||
LED indicator | Power supply, charging green, fault red | |||||||
LCD | HD high-brightness industrial resistance display | |||||||
