Wind Cooling Box Ev Charging Station DC 7KW 11KW 22KW 30KW 120KW Public

Name: Wind Cooling Box Ev Charging Station DC 7KW 11KW 22KW 30KW 120KW Public
Brand: KIWI
SKU: Commercial EV Charger
Price: 320.00 USD
Availability: InStock
Rating: 4.7 (174 reviews)

All Products

AC EV Chargers
(32)

DC EV Chargers
(43)

Charger Accessories
(5)

Core Services
(10)

Old Version Products
(398)

I'm Online Chat Now

Wind Cooling Box Ev Charging Station DC 7KW 11KW 22KW 30KW 120KW Public

Large Image : Wind Cooling Box Ev Charging Station DC 7KW 11KW 22KW 30KW 120KW Public

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	KIWI
Model Number:	Commercial EV Charger

Payment & Shipping Terms:

Minimum Order Quantity:	2 pieces
Price:	$320.00 - $40,050.00/pieces
Packaging Details:	Carton/wooden box
Supply Ability:	10000 Piece/Pieces per Month

Contact Now

Wind Cooling Box Ev Charging Station DC 7KW 11KW 22KW 30KW 120KW Public

Description

Interface Standard:	Type1 , Type2 , CCS , CHAdeMO , GB/T	Output Current:	600A Max
Output Power:	240KW Max	Input Voltage:	AC 220V - 380V
Installation Method:	AC: Wall Mount, DC: Ground Mount	Start-up And Billing Method:	Plug&Charge / RFID / APP / Ocpp
Charging Connector:	Type1 , Type2 , CCS , CHAdeMO , GB/T	Output Voltage Range:	DC 1000V Max ; AC 380V Max
Cooling Method:	Wind Cooling	Plug Wire Length:	5M (Customizable)
Operation Life:	≥10000	Port:	Shenzhen,Foshan,etc.
Highlight:	ev charging station dc 7KW , ev box charging station , ev charging station 11KW

Wind cooling AC DC 7KW 11KW 22KW 30KW 120KW KIWI Public ev connect charging stations

Shenzhen Kiwi Technology Co., Ltd.

As a solution provider, we can help you calculate the cost of use and match the best product solution with the local policy.

Questions Before Browsing

⚪ Where is your location?

⚪ What are the popular car models in your location?

⚪ How many EVs are expected to be parked in your parking lot?

⚪ What is the policy of local EV charger installation?

Why Parking Lots Need EV Charger

As the number of electric vehicles increases worldwide, the number of EV charger has become severely insufficient, if you can install EV chargers in time, you will get: 1. Improve the satisfaction and property prices of residential areas and office areas. 2. Attract more visitors to the business area and increase the length of stay of visitors. 3. Add convenience to employees of hospitals or government agencies. 4. Increase the revenue of the parking lot and prepare for the subsequent increase in the number of electric vehicles.

AC or DC

AC Charging

AC level 2 charging is the most common form to power EVs. This power still relies on the standard AC, but uses a transformer to raise the voltage and increase the speed with which level 2 can top up an EV. Level 2 charging is a great option for homes, multi-unit dwellings and other businesses.

DC Charging

Level 3 charging is also known as “fast charging” (DCFC) or “rapid charging” (DCRC), it is the fastest way to power an EV. Though it requires more initial setup cost and construction, the stability of DC power in level 3 charging can top up an empty EV battery in as little as 30 minutes.

Some Cases for You

Hotel underground parking lot

AC 7KW *10 & DC 30KW *6 & DC 120kw *4

Airport open parking lot

DC 120KW *20

For places such as residential areas, hotels, and office buildings that have a lot of time for vehicle charging, it is recommended to install AC and DC chargers at the same time, so that you can take care of a variety of vehicles, and for airports, charging stations, convenience stores and other scenarios where it is inconvenient for vehicles to park and charge for a long time, it is recommended to install DC fast chargers.

If you would like to have your own solution, please contact our engineers

Products Description

Model Numbers	AC 220V-7KW	AC 380V-11KW	AC 380V-22KW
Output Current	0~32A	0~16A	0~32A
Input Voltage	AC 220V 50/60HZ	AC 380V 50/60HZ	AC 380V 50/60HZ
Output Voltage	220V Single-phase	380Vac+/-10% Three-phase	380Vac+/-10% Three-phase
Charging Connector	Type1, Type2, GB/T
Charging Standard	IEC61851, IEC62196
Charging Mode	Plug&Charge/RFID/ APP/OCPP
Size	202104388mm
Weight	<6kg (Without column)
Input Line Length	Side open entry
Leakage Protection	Type B RCD AC 30mA +DC 6mA
Plug Wire Length	5M (Customizable)
Connection Method	Method C (Plug wire version)
Lndicator Light	LED Status Light
Protection Level	IP65
Operation Temperature	-20℃ - 55℃
Working Humidity	5%-95%
Installation Method	Wall, Column (optional)
Altitude Limitation	≤2000m
Operation Life	≥10000
More Parameters	Click to get

Model	60KW	120KW	240KW
Input Voltage	0~200A	0~400A	0~600A
Input Current	AC 380V , 50/60HZ
Output Voltage	DC 200V~1000V
Charging Connector	CCS1 , CCS2 , CHAdeMO , GB/T
Charging Standard	IEC61851 , IEC62196 , ISO15118
Charging Mode	Plug&Charge , RFID , APP , OCPP1.5j / 1.6j
Size	7003401670 mm	7003401670 mm	7727631966 mm
Weight	>258kg
Input Current	AC 0A~182A; 50mm cable	AC 0A~230A; 75mm cable	AC 0A~364A, 90mm cable
Leakage Protection	RCD AC 30mA
Plug Wire Length	5M (Customizable)
Cooling Method	Wind Cooling
Protection Level	IP54
Operation Temperature	-20℃-55℃
Relative Humidity	5%-95%
Altitude Limitation	≤2000m
Operation Life	≥10000
More Parameters	Click to get

Contact us for more product picture and parameter.

Customizable Options

We will recommend you different charging guns according

to your location or provide charging guns according to your needs

Please contact us to discuss the details of the solution

Why Choose Us

Shenzhen Kiwi Technology Co.,Ltd.

Our company a high-tech enterprise specializing in complete ev charging solution from high-quality AC EV wallboxes, reliable DC EV fast charging stations with robust connectivity, App/PC operation software to innovative on-demand ev charging systems. Kiwi has 4 production bases with modern workshops, complete production line and advanced testing equipments. One of them is covered more than 26,000㎡. Kiwi has passed 1S09001, ISO14001 and ISO16949 certification.

The group has 2 sub-brands

Established 8 years ago

Global Sites 10+

Regional access certificate 15+

20+ R&D engineers

Served 29 countries

120

120+ experienced employees

330

330+ orders per year

2200

OCPP loading devices 2200+
