EV 60kW 80kW 120kW 150kW Ocpp CCS 2 DC Charging Pile Fast Electric Car EV Charging Stations

EV 60kW 80kW 120kW 150kW Ocpp CCS 2 DC Charging Pile Fast Electric Car EV Charging Stations
EV 60kW 80kW 120kW 150kW Ocpp CCS 2 DC Charging Pile Fast Electric Car EV Charging Stations EV 60kW 80kW 120kW 150kW Ocpp CCS 2 DC Charging Pile Fast Electric Car EV Charging Stations EV 60kW 80kW 120kW 150kW Ocpp CCS 2 DC Charging Pile Fast Electric Car EV Charging Stations EV 60kW 80kW 120kW 150kW Ocpp CCS 2 DC Charging Pile Fast Electric Car EV Charging Stations EV 60kW 80kW 120kW 150kW Ocpp CCS 2 DC Charging Pile Fast Electric Car EV Charging Stations EV 60kW 80kW 120kW 150kW Ocpp CCS 2 DC Charging Pile Fast Electric Car EV Charging Stations

Large Image :  EV 60kW 80kW 120kW 150kW Ocpp CCS 2 DC Charging Pile Fast Electric Car EV Charging Stations

Product Details:
Place of Origin: Guangdong, China
Brand Name: KIWI
Model Number: Commercial EV Charger
Payment & Shipping Terms:
Minimum Order Quantity: 2 pieces
Price: CN¥47,636.19-86,181.50/pieces
Contact Now

EV 60kW 80kW 120kW 150kW Ocpp CCS 2 DC Charging Pile Fast Electric Car EV Charging Stations

Description
Interface Standard: Type1 , Type2 , CCS , CHAdeMO , GB/T Output Current: 500A Max
Output Power: 60KW 120KW 150KW Input Voltage: AC 380V, AC380V~400V 50/60Hz
Output Volta: DC 150V~1000V Output Curren: 0~200A, 0~400A, 0~500A
Charging Connector: CCS1 / CCS2 / CHAdeMO / GBT Charging Standard: IEC61851 IEC62196, ISO15118
Charging Mode: RFID/ APP/OCPP 1 .5j/2.01j Size: 545*705*1675mm
Weight: >325kg Leakage Protection: RCD AC 30m
Plug Wire Length: 5M ( Customizable)
Highlight:

120kW DC Charging Pile

,

150kW DC Charging Pile

,

Ocpp CCS 2 DC Charging Pile

EV 60kW 80kW 120kW 150kW Ocpp CCS 2 DC Charging Pile Fast Electric Car EV Charging Stations 0
EV 60kW 80kW 120kW 150kW Ocpp CCS 2 DC Charging Pile Fast Electric Car EV Charging Stations 1
EV 60kW 80kW 120kW 150kW Ocpp CCS 2 DC Charging Pile Fast Electric Car EV Charging Stations 2
EV 60kW 80kW 120kW 150kW Ocpp CCS 2 DC Charging Pile Fast Electric Car EV Charging Stations 3
EV 60kW 80kW 120kW 150kW Ocpp CCS 2 DC Charging Pile Fast Electric Car EV Charging Stations 4
EV 60kW 80kW 120kW 150kW Ocpp CCS 2 DC Charging Pile Fast Electric Car EV Charging Stations 5
Output power
kW-60S
kW-120S
kW-150S
Input Characteristic
AC Input Power
115A, 400V
182A, 400V
228A, 400V
Input type
3P + N + PE


Input Voltage Range
AC380V~400V


Input Frequency
50Hz /60Hz


THD
≤5%


Ouput Characteristic
DC Output Power Rating (MAX)
60kW
120kW
150kW
DC Output Voltage
150-1000VDC


Cable Length
5M or Customized


Others
Distribution Systems
TN-S. TN-C, TN-C-S, TT (required external RCD)


Connector Type
3P + N + PE


Protection
Overcurrent, overvoltage, undervoltage, integrated surge protection, ground fault including DC leakage protection, door opening
protection


Power Factor (Full Load)
≥0.98


Standby Power
≤5%


Standby Power
<36W


Short Circuit Current
10kA


Pre-charge Current
<1A


Inrush Current
<55A
Leakage Current
0.8mA


Energy Metering
Standard: Meter for DC outlet, Optional: AC inlet
Cellular Communication
GSM, 4G, LTE
USER INTERFACE
Connectivity
Internet access via 4G/3G/Ethernet (RJ45)
User Authentication
RFID, QR code
User Interface
7 inch LCD high-contrast touchscreen
Communiation Protocols
Proprietary and OCPP 1.6J/2.0
RFID Reader
ISO/IEC 14443 A/B Mifare RFID reader
Emergency Button
Yes
Language System
English, Chinese or Customized
GENERAL CHARACTERISTIC
Protection Rating
IP55 and IK10 (cabinet) / IK08 (touchscreen)
Operating Altitude
≤ 2000m
Operating Temperature
- 20 °C to 55 °C
Storage Temperature
-40 °C to 70 °C
Humidity
< 95%, non-condensing
Mounting
Free-standing cabinet
Dimensions (mm）
545*705*1675mm
Net Weight (kg)
≤258kg
≤285kg
≤325kg
COMPLIANCE STANDARDS
Codes & Standards
IEC 61851-21-2, IEC 61000, IEC/EN 61851-1, IEC 61851-23, IEC 61851-24, IEC 62196-1, IEC 62196-3, GBT18487, GBT20234, NB/T 33008.1,
NB/T 33001
Communication to the EV
DIN 70121, ISO/IEC 15118, GBT27930, GBT 34657, GBT 34658
EV 60kW 80kW 120kW 150kW Ocpp CCS 2 DC Charging Pile Fast Electric Car EV Charging Stations 6
EV 60kW 80kW 120kW 150kW Ocpp CCS 2 DC Charging Pile Fast Electric Car EV Charging Stations 7
EV 60kW 80kW 120kW 150kW Ocpp CCS 2 DC Charging Pile Fast Electric Car EV Charging Stations 8


FQA

Q: How is your electric vehicle charging station after-sale service?
A:1/We will build a whatsapp/skype/wechat service group with technical engineers and company leader if need;
2/We provide 24/7 online service,so you're welcome to contact us any time you need;
3/Will change the part for free during warranty if non-human damage,for other problems,we'd like to supply customer the part at original cost.

Q: How is your payment method?
A: Same as other ev charging stations suppliers,normally 30%-50% deposit and balance paid off before shipment,
special requirement customer please contact us for further discussion.

Q: How long is your normal delivery time?
A: 1/For stock ev charger,can arrange the shipment immediately after you confirm the order;
2/For custom AC ev charger less than 100pcs,normally 7-15 days;
3/For custom DC ev charger less than 100pcs,normally 15-25 days;

Q: Can I use my own card or app at your electric car charging stations?
A: Normally the RFID card and app have to identify our electric charger,so we will provide you 3 free RFID card for each
charger.

Q:Will your electric car charger charging slower in winter?
A:The electric charging station may need a little longer warm up time before normal run,but this is very small change,it won't influence the output power,so we can ignore this influence.

Q:Can you provide a video how to install the electric vehicle charger?
A:Yes we have the installation guide video,it's very easy and anyone who know a little about electricity safety can finish this work,we will also be ready online to help your any possible question.

Q:How can I become your exclusive agency? A:Only if you have this interest,you can be our agent if we don't have exclusive agent in your market. if you want to be exclusive agent,we will have an annual sales amount target requirement,welcome to further discuss about more details,we're open to any constructive advice.
